Surveying Instrument GPS RTK Base and Rover Unistrong G970C Pro/S631 Gps Rtk Gps Rove GNSS GPSS RTK RECEIVER

Brand Name : Unistrong

Model Number : G970C PRO

Place of Origin : China

MOQ : 1 piece

Price : $5,000.00

Payment Terms : L/C, T/T

Supply Ability : 1 ~ 30 day

Delivery Time : 30 work day

Product name : RTK receiver Unistrong G970C PRO Base and Rover

Customized support : OEM

Channel : 1408 Channels

Color : yellow

Material : Magnesium alloy shell

Galileo : E1,E5a,E5b,ALTBOC,E6

GPS : L1C/A,L1C,L1P,L2C,L2P,L5

BDS : B1I,B2I,B3I,B1C,B2a,B2b,ACEBOC

Contact Now

Surveying Instrument GPS RTK Base and Rover Unistrong G970C PRO Gps Rtk Gps Rove GNSS GPSS RTK RECEIVER

Overview
Product Description

G970IIPro supports GPS, GLONASS, BDS, GALILEO and other systems to receive multi-frequency signals. The build-in "Lyra" baseband chip is able to provide more channels. The receiver supports "Atlas" L-Band signals and can achieve centimeter-level positioning. In addition, a new combination antenna is used to integrate GNSS, WiFi, Bluetooth and 4G to perform better in complex environments.
Product Features
- "Lyra" Baseband Chip
Integrated 800 channels,supporting multi-constellation and multi-frequency.
- Atlas
Supporting "Atlas" L-Band, with global centimeter-level positioning accuracy on a single receiver.
-Multi-communications network 4G
Built-in high-speed network module supporting Multi-network 2/3 / 4G.
-Tilt surveying 2.0
New tilt surveying algorithm makes easy coordinate collection.
-Combination Antenna
The new combination antenna integrates GNSS, WiFi, Bluetooth, and 4G with better wireless signal. The signal-to-noise ratio of GNSS satellites is increased by 2dB on average. Better RTK performance in complex environments.

Product Details
S631 GNSS Receiver Specifications
Number of channels
1408
394
Tracking characteristics
GPS: L1C/A,L1C,L1P,L2C,L2P,L5
BDS: B1I,B2I,B3I,B1C,B2a,B2b,ACEBOC
GLONASS: G1,G2,G3
Galileo: E1,E5a,E5b,ALTBOC,E6
QZSS: L1C/A,L1C,L2C,L5,LEX
SBAS
GPS: L1CA/L1P/L1C/L2P/L2C/L5
GLONASS: G1/G2, P1/P2
BeiDou: B1/B2 (B3 separate variant without L5)
Galileo: E1BC/E5a/E5b
QZSS: L1CA/L2C/L5/L1C
Accuracy indicators
Update rate
10Hz standard configuration, 20Hz/50Hz can be authorized
5Hz
Static accuracy
Horizontal: ± (2.5+1 × 10-6D) mm
Vertical: ± (5+1 × 10-6D) mm
RTK accuracy
Horizontal: ± (8+1 × 10-6D) mm
Vertical: ± (15+1 × 10-6D) mm
RTKFusion
30 ° rod tip positioning accuracy within 2cm, 60 ° rod tip positioning accuracy within 5cm
Note: 1.8-meter pole height situation
Electrical performance
Battery characteristics
Dual battery, 7.2V/3400mAh * 2. At room temperature, the mobile station radio mode can support no less than 9 hours of operation.
input voltage
9~28V DC
system configuration
operating system
Linux
Built in storage
8G onboard; TF card extension, maximum support of ≥ 32G
Bluetooth
V5.0+EDR backward compatibility/BLE
WIFI
802.11 b/g/n
Network communication
GSM:900/1800MHz
CDMA 1x/EVDO:BC0
WCDMA:B1
TD-SCDMA:B34/B39
FDD LTE:B1/B3/B8
TDD LTE:B38/B39/B40/B41
UHF radio station
TRM101: Power 1W, frequency 410-470MHz
Communication protocol
TrimTalk 450S, PCC GMSK, SATEL,
HITARGET(9600), HITARGET(19200), TrimTalk(4800),
HZSZ, South 9600, TrimMark III, South 19200, GEOTALK, GEOMARK
Tilt measurement
support
data interface
TNC
Connect the antenna of the built-in radio station.
5-core interface
Used to connect external power sources and external radio stations.
7-core interface
Used to connect PC or handheld devices, USB+serial port.
Other
SIM card slot and TF card slot, installing SIM card and TF card
man-machine interface
Keys
Power button, used to turn on and off the host.
Short press once to report the current working mode and status.
Indicator light
Power supply (red green dual color)
Green constantly on: battery level 30% -100%; Green flashing: battery level 10% -30%;
Satellite (red green dual color)
Off: No stars received;
Flashing red light: received the star, but did not locate it successfully;
Green light flashing:positioned but not fixed; Green light always on: fixed release;
Flashing red and green lights alternately: GNSS motherboard abnormal.
Bluetooth (blue monochrome)
Off: No Bluetooth connection established with the device;
Chang Liang: Establish a Bluetooth connection with the device.
Data link (green blue dual color)
Green light always on: The data link has been successfully set up;
Green light flashing: normal data transmission; Blue light flashing: In static mode, the blue light flashes according to the set static sampling interval.
Voice
Support TTS voice broadcasting
physical characteristics
Integrated antenna
Integrated integrated antenna
Size
156mm*76mm
Weight
Approximately 1.2KG
Environmental performance
working temperature
-45℃ ～ +75℃
Storage temperature
-55℃ ～ +85℃
Waterproof and dustproof
IP68
Falling
It can withstand a drop of 2 meters from the pole at room temperature (on a hardwood ground), with a free drop of 1.2 meters.
Humidity
Anti 100% condensation
